Gevello Stable Ring – Timeless Design in Premium Stainless Steel

What is a stable tie ring used for?

A stable ring provides a fixed attachment point for a rope, lead or chain. These rings are commonly used in:

• horse stables and calf barns;
• grooming and wash areas;
• paddocks and pasture areas;
• barns and agricultural buildings;
• other locations that require a neat, fixed attachment point.

The right design depends on its intended use, the supporting surface and the conditions in which the ring will be installed.

Galvanised steel or AISI 316 stainless steel?

A galvanised tie ring is an economical option for general use. The zinc coating protects the steel underneath against corrosion, but it may gradually wear if the surface is damaged or heavily used.

A stable ring made from AISI 316 stainless steel is particularly suitable for damp areas and outdoor locations. The material is highly corrosion-resistant and retains its neat appearance when regularly exposed to moisture, dirt and changing weather conditions.

AISI 316 stainless steel is therefore a practical choice if you value:

• a long service life;
• a clean, professional appearance;
• good corrosion resistance;
• indoor and outdoor use;
• a mounting point without a prominent fixing plate.

A neat fixing in concrete

The AISI 316 stainless steel stable ring from Staalkabelstunter is supplied with a concrete anchor bolt and a stainless steel cover rosette. The anchor is designed for installation in a suitable solid surface. The cover rosette then conceals the drilled hole and gives the fixing a clean finish.

How do you install a stable ring with an anchor bolt?

Before installation, always check that the supporting surface is suitable and sufficiently strong. A concrete anchor is intended for an appropriate solid surface. Do not install it in hollow brick, thin panels or an unknown wall construction without obtaining suitable technical advice.

1. Choose the correct position for the stable ring.
2. Drill a straight hole with the specified diameter of 14 mm.
3. Carefully remove all drilling dust from the hole.
4. Insert and secure the anchor in accordance with its installation instructions.
5. Finish the fixing with the stainless steel cover rosette.
6. Regularly inspect the ring and surrounding surface for movement, wear or damage.

If you are unsure about the supporting surface or expected load, have the installation assessed by a suitably qualified person.

Tips for positioning and installation

• Choose a solid supporting surface. Only install the supplied anchor in suitable masonry or concrete. Use a fixing system specifically intended for wood, hollow brick or sheet material when working with those surfaces.
• Check the drilling location. Before drilling, make sure there are no pipes, electrical cables or other obstructions behind the chosen position.
• Drill straight and accurately. Use a suitable 14 mm masonry or concrete drill bit and keep the drill as straight as possible. Follow the anchor instructions for the required drilling depth.
• Clean the drilled hole thoroughly. Remaining dust can reduce the effectiveness of a mechanical anchor. Clean the hole carefully before inserting the anchor.
• Tighten the fixing correctly. Follow the tightening torque specified by the supplier. An under-tightened anchor may move, while excessive tightening may damage the fixing or supporting surface.
• Fit the cover rosette last. First check that the ring is straight and firmly secured, then cover the drilled hole with the stainless steel rosette.
• Select a practical position. Consider the intended use, the space around the ring and the rules that apply at your stable. If in doubt, ask an experienced professional to determine the appropriate mounting height for tying animals.
• Inspect the installation regularly. Check the ring, anchor and surrounding wall for looseness, cracks, deformation or other damage.

Please note: the supplied concrete anchor is generally not suitable for installation in a horse trailer or thin wall. Use fixing hardware designed for the specific construction and seek professional advice if you are unsure.

When should you choose this stainless steel stable ring?

This design is particularly suitable when you need a compact, durable and professional-looking attachment point. Unlike a conventional ring on a visible plate, the fixing is neatly concealed behind a stainless steel cover rosette.

This makes the ring suitable for modern horse stables, professional grooming areas, calf barns and other locations where function and appearance both matter.

Frequently asked questions

Can the stable ring be used outdoors?

Yes. AISI 316 stainless steel is highly resistant to moisture and weather exposure, making it suitable for indoor and outdoor use.

What drill size is required?

The supplied anchor requires a drilled hole with a diameter of 14 mm.

Can the ring be fitted to any wall?

No. Always check the material and condition of the supporting surface first. Obtain suitable advice for hollow brick, sheet material or an unknown wall construction.

Can this ring be used for lifting?

No. The stable ring is not intended for lifting, climbing or personal safety applications.
